Philips LPC2129 - Page 35

Introduction 35 May 03, 2004
Philips Semiconductors Preliminary User Manual
LPC2119/2129/2194/2292/2294ARM-based Microcontroller
0xE0044050 C1TFI3
CAN1 Tx
Frame
Information
Register
(buffer 3)
FF RTR - - - - - -
R/W
0x0000
0000
- - - - DLC
- - - - - - - -
PRIO
0xE0044054 C1TID3
CAN1 Tx
Identifier
Register
(buffer 3)
- - -
R/W
0x0000
0000
29-bit (FF=1) or
11-bit data (FF=0) ID
0xE0044058 C1TDA3
CAN1
Tx Data
Register A
(buffer 3)
Data 4
R/W
0x0000
000
Data 3
Data 2
Data 1
0xE004405C C1TDB3
CAN1
Tx Data
Register B
(buffer 3)
Data 8
R/W
0x0000
000
Data 7
Data 6
Data 5
CAN2 Interface
0xE0048000 C2MOD
CAN2 Mode
Register
- - - - - - - -
R/W
0x0000
0001
- - - - - - - -
- - - - - - - -
TM
- RPM SM TPM STM LOM RM
0xE0048004 C2CMR
CAN2
Command
Register
- - - - - - - -
W0 NA
- - - - - - - -
- - - - - - - -
STB3 STB2 STB1 SRR CDO RRB AT TR
0xE0048008 C2GSR
CAN2 Global
Status
Register
8-bit data TXERR
RO
0x0000
000C
8-bit data RXERR
- - - - - - - -
BS ES TS RS TCS TBS DOS RBS
0xE004800C C2ICR
CAN2
Interrupt and
Capture
Register
- - -ALCBIT
RO
0x0000
0000
ERRC
ERR
DIR
ERRBIT
- - - - -TI3TI2IDI
BEI ALI EPI WUI DOI EI TI1 RI
