0xE004C030 C3TFI1
CAN3 Tx
Frame
Information
Register
(buffer 1)
FF RTR - - - - - -
R/W
0x0000
0000
- - - - DLC
- - - - - - - -
PRIO
0xE004C034 C3TID1
CAN3 Tx
Identifier
Register
(buffer 1)
- - -
R/W
0x0000
0000
29-bit (FF=1) or
11-bit data (FF=0) ID
0xE004C038 C3TDA1
CAN3
Tx Data
Register A
(buffer 1)
Data 4
R/W
0x0000
000
Data 3
Data 2
Data 1
0xE004C03C C3TDB1
CAN3
Tx Data
Register B
(buffer 2)
Data 8
R/W
0x0000
000
Data 7
Data 6
Data 5
0xE004C040 C3TFI2
CAN3 Tx
Frame
Information
Register
(buffer 2)
FF RTR - - - - - -
R/W
0x0000
0000
- - - - DLC
- - - - - - - -
PRIO
0xE004C044 C3TID2
CAN3 Tx
Identifier
Register
(buffer 2)
- - -
R/W
0x0000
0000
29-bit (FF=1) or
11-bit data (FF=0) ID
0xE004C048 C3TDA2
CAN3
Tx Data
Register A
(buffer 2)
Data 4
R/W
0x0000
000
Data 3
Data 2
Data 1
0xE004C04C C3TDB2
CAN3
Tx Data
Register B
(buffer 2)
Data 8
R/W
0x0000
000
Data 7
Data 6
Data 5
Table 2: LPC2119/2129/2194/2292/2294 Registers
Address
Offset
Name Description MSB LSB Access
Reset
Value
