LPC2119/2129/2194/2292/2294ARM-based Microcontroller
0xE0050010 C4IER
CAN4
Interrupt
Enable
Register
- - - - - - - -
R/W
0x0000
0000
- - - - - - - -
- - - - - TIE3 TIE2 IDIE
BEIE ALIE EPIE WUIE DOIE EIE TIE1 RIE
0xE0050014 C4BTR
CAN4 Bus
Timing
Register
- - - - - - - -
R/W
0x001C
0000
SAM TSEG2 TSEG1
SJW - - - - 10-bit data>>>
<<< 10-bit data BRP
0xE0050018 C4EWL
CAN4 Error
Warning Limit
Register
- - - - - - - -
R/W
0x0000
0060
- - - - - - - -
- - - - - - - -
EWL
0xE005001C C4SR
CAN4 Status
Register
- - - - - - - -
RO
0x000C
0C0C
BS ES TS3 RS TCS3 TBS3 DOS RBS
BS ES TS2 RS TCS2 TBS2 DOS RBS
BS ES TS1 RS TCS1 TBS1 DOS RBS
0xE0050020 C4RFS
CAN4 Rx
Frame Status
Register
FF RTR - - - - - -
R/W
0x0000
0000
- - - - DLC
- - - - - BP 10-bit data>>>
<<< 10-bit data ID Index
0xE0050024 C4RID
CAN4 Rx
identifier
Register
- - -
R/W
0x0000
0000
29-bit (FF=1) or
11-bit data (FF=0) ID
0xE0050028 C4RDA
CAN4
Rx Data
Register A
Data 4
R/W
0x0000
0000
Data 3
Data 2
Data 1
0xE005002C C4RDB
CAN4
Rx Data
Register B
Data 8
R/W
0x0000
0000
Data 7
Data 6
Data 5
Table 2: LPC2119/2129/2194/2292/2294 Registers
Address
Offset
Name Description MSB LSB Access
Reset
Value
