Philips LPC2129 - Page 46

Introduction 46 May 03, 2004
Philips Semiconductors Preliminary User Manual
LPC2119/2129/2194/2292/2294ARM-based Microcontroller
0xFFE0000C BCFG3
Conf. Reg. for
mem bank 3
AT MW (0x0) BM WP
WP
ERR
BUS
ERR
R/W
0x0000
FBEF
--------
WST2 RBLE WST1
WST1 - IDCY
Vectored Interrupt Controller - VIC
0xFFFFF000
VICIRQ
Status
IRQ Status
Register
32-bit data RO 0
0xFFFFF004
VICFIQ
Status
FIQ Status
Register
32-bit data RO 0
0xFFFFF008
VIC
RawIntr
Raw Interrupt
Status Reg.
32-bit data RO 0
0xFFFFF00C
VICInt
Select
Interrupt
Select Reg.
32-bit data R/W 0
0xFFFFF010
VICInt
Enable
Interrupt
Enable Reg.
32-bit data R/W 0
0xFFFFF014
VICInt
EnClear
Int. Enable
Clear Reg.
32-bit data WO 0
0xFFFFF018
VICSoft
Int
Software
Interrupt Reg.
32-bit data R/W 0
0xFFFFF01C
VICSoftI
ntClear
Software Int.
Clear Reg.
32-bit data W 0
0xFFFFF020
VIC
Protection
Protection
Enable Reg.
32-bit data R/W 0
0xFFFFF030
VIC
Vect
Addr
Vector
Address Reg.
32-bit data R/W 0
0xFFFFF034
VICDef
V
ectAddr
Default Vec.
Addr.Reg.
32-bit data R/W 0
0xFFFFF100
VIC
Vect
Addr0
Vector
adr. 0 reg.
32-bit data R/W 0
0xFFFFF104
VIC
Vect
Addr1
Vector
adr. 1 reg.
32-bit data R/W 0
...
0xFFFFF13C
VIC
Vect
Addr15
Vector
adr. 15 reg.
32-bit data R/W 0
Table 2: LPC2119/2129/2194/2292/2294 Registers
Address
Offset
Name Description MSB LSB Access
Reset
Value
