MAINTENANCE PROCEDURES : EDGE MOTOR ASSEMBLY REMOVAL
02.9687.0010 0 33
2
Step 9. Reinstall by performing steps in reverse.
Note: When reinstalling edge motor assembly, the connector orientation should face in the downward
position as shown in Figure 2-15.
Figure 2-15: Edge Motor Assembly Connector Orientation
Note position of edge
motor connector.
