Supplementary data
Operating Manual PNOZ s30
1001715-EN-19
| 122
Please note:
For the "sensor" subsystem, a minimum speed must be exceeded within forced dynamisa-
tion.
See under 2 encoder diagnostics / broken shearpin monitoring [ 21].
13.3.9 Safety-related characteristic data for operation with 2 proximity
switches
13.3.9.1 Permitted encoder types and output signals
Non-safety-related rotary encoder
Permitted encoder types:
} Inductive proximity switches
Permitted output circuits:
} pnp - N/O contact
} npn - N/O contact
13.3.9.2 Safety-related architecture
Sensor
proximity switch
Actuator
SRP/CS
Actuator
SRP/CS
Sensor
PNOZ s30
Logic
+
Diagnostic
SRP/CS
Logic
Sensor
proximity switch
