Function description
Operating Manual PNOZ s30
1001715-EN-19
| 16
NOTICE
The individual blocks are galvanically isolated from each other:
– Supply voltage: A1, A2
– Encoder and initiator inputs: GND, In1, In2, RJ45 socket and shield
– Start and feedback circuits: S21, S11, S34, Y1, Y2
– Semiconductor outputs and select inputs: Y30, Y31, Y32, Y33, Y34,
Y35, Y10, Y11, Y12, Y13
– Relay output 13, 14
– Relay output 11, 12
– Relay output 23, 24
– Relay output 21, 22
If possible, the connections for the various earth potentials (GND, S21, Y30
und A2) should not be connected on the PNOZ s30 but should be connec-
ted directly to the GNDs on the connected units, otherwise noise susceptib-
ility may be increased significantly (conductor loops are not permitted).
5.3 Functions
The following monitoring functions can be configured:
5.3.1 Standstill
With standstill monitoring, the output is switched on when the value falls below the stated
standstill value; if the standstill value is exceeded, the output switches off.
