Display menu - Configuration
Operating Manual PNOZ s30
1001715-EN-19
| 67
8.7 Menu overview
The tables provide an overview of the menu settings.
8.7.1 Permanent display
If no settings are made, information regarding the configuration and current values are
shown on the display.
You can change the permanent display on the display in the "Settings" menu.
8.7.2 Basic settings Ini pnp pnp
Settings for basic configuration 1
Level Designation
on the display
Description Settings
1 Basic Parameter
Ini pnp pnp
Default:
Load?
Select the default settings with
which the basic configuration
menu Ini pnp pnp is to be called:
-Load: The basic parameters are
loaded. Then it switches to the ba-
sic menu Ini pnp pnp.
The basic parameters should al-
ways be loaded when commis-
sioning for the first time.
- Edit?: The basic parameters are
not loaded, i.e. all parameters are
retained. The basic menu para-
meters can be changed within the
permitted boundaries.
- Escape: Exits the basic menu.
2 Standstill
Rel.1 Out 1
Default:
2.00Hz
Enter standstill frequency 100 mHz ... 10.0Hz
2 v max
Rel.2 Out 2
Default:
500Hz
Enter the max. permitted speed 10 mHz ... 3.00kHz
Other, pre-defined settings:
} Encoder type
2 pnp type proximity switches
} Parameter set/select input
P0, select inputs are ignored (Select inputs mode: "None")
