Display menu - Configuration
Operating Manual PNOZ s30
1001715-EN-19
| 78
8.7.5 Advanced settings
Level Menu designation Description Settings
1 Positions Paramet-
ers
Settings for position monitoring
functions
2 Position (1 ... 4)
Start mode
Default:
Monitored /
Enter start type for position monit-
oring
} Monitored /
} Automatic
2 Position (1 ... 4)
Window width
Default:
1 pulse
Enter width of position window for
position monitoring functions 1 ...
4
1 ... 24,900,000 pulses
or the corresponding value in the selec-
ted unit
1 Direction Parameter Settings for direction monitoring
2 Direction
Autoreset
Default:
deactivated
Activate/deactivate automatic re-
set of the direction monitoring
} deactivated
} activated
2 (Direct. Left max.
right, Direct. Right
max. left)
Default:
0 pulses
Enter max. tolerated number of
pulses (or Edg, m, rot) in the
wrong direction.
1 ... 24,900,000 pulses
or the corresponding value in the selec-
ted unit
1 Mode
Select Input
Default:
None
Setting for using the select inputs
} All 16
} 1 from 4
} None
1 Delay
Select Input
Default:
tdl: 0 ms
Enter delay time of the select in-
puts Y10 – Y13
Info: The states of the select in-
puts are only adopted if they were
unchanged during the set time.
0 ... 30.0 s
1 2-Encoder dia-
gnostics
Comparison of f
AB
and f
Z
2 Activation speed On both encoders, speed v
ABZ
from which the check is carried
out.
v
ABZ
= 0 (check is always carried out)
v
ABZ
= 10 mHz … 1MHz
1 Frequency filter
Default:
Off
Filtering of the measured speed
} Off
} Fast
} Moderate
} Slow
