Page #87 background image
Create configuration in PNOZsigma Configurator
Operating Manual PNOZ s30
1001715-EN-19
| 87
9 Create configuration in PNOZsigma Configurator
For devices PNOZ s30 from Version 2.2 you have the opportunity to perform the configura-
tion in the software tool PNOZsigma Configurator.
The PNOZsigma Configurator can be downloaded from the Internet in the download area of
the Pilz website.
With the PNOZsigma Configurator you can configure all the functions that are described in
the function description.
In Version 1.0. and 1.1 of the PNOZsigma Configurator the configuration is downloaded via
the chip card reader PNOZ Chip Card Reader. From Version 1.2 of PNOZsigma Configur-
ator you can perform the download alternatively via the cable PNOZ s30 USB-configura-
tion-cable. Both are available from Pilz as accessories [ 129].
9.1 Download project from the PNOZsigma Configurator to the
PNOZs30
CAUTION!
Perform a commissioning test every time that you download a project to the
PNOZs30.
CAUTION!
With each transfer, you must check that the appropriate configuration for an
application is transferred to a device!
Download project via the chip card from the PNOZsigma Configurator to the
PNOZs30
1. Open the PNOZsigma Configurator and create your configuration.
2. Remove the chip card from the PNOZ s30 and insert it into the holder for the chip card
reader.
3. In the PNOZsigma Configurator, click on the project to be downloaded in the Project
Overview and click on the button in the project to download the configuration to
the chip card.
4. When the download is complete, remove the chip card from the chip card reader and
insert it into the PNOZs30 again.
5. To save the configuration on the PNOZ s30 follow the instructions given in chapter
Read data from chip card [ 61].
6. To ensure that the configuration has been transferred correctly, check that the Config-
uration CRC in the PNOZs30 matches the CRC that is shown in the title bar in the
PNOZsigma Configurator.
