Safety
Operating Manual PNOZ s30
1001715-EN-19
| 12
3 Safety
3.1 Intended use
The speed monitor monitors standstill, speed, speed range, position and direction in ac-
cordance with EN ISO 13849-1 up to PL e and EN IEC 62061 up to SIL CL 3.
The safety controller should be installed in a protected environment that meets at least the
requirements of pollution degree 2. Example: Protected inside space or control cabinet with
protection type IP54 and appropriate air conditioning.
WARNING!
Users must take appropriate measures to detect or exclude errors (e.g. slip-
page or broken shearpin) which cause the frequency of the encoder signal
to no longer be proportional to the monitored speed.
Appropriate measures are:
– Using the monitored encoder to also control the drive
– Mechanical solutions
– Z-frequency monitoring with an additional proximity switch (Ini pnp)
on the same axis
NOTICE
EMC-compliant electrical installation
The product is designed for use in an industrial environment. The product
may cause interference if installed in other environments. If installed in other
environments, measures should be taken to comply with the applicable
standards and directives for the respective installation site with regard to in-
terference.
3.2 Safety regulations
3.2.1 Safety assessment
Before using a device, a safety assessment in accordance with the Machinery Directive is
required.
The product as an individual component fulfils the functional safety requirements in accord-
ance with EN ISO 13849 and EN 62061. However, this does not guarantee the functional
safety of the overall plant/machine. To achieve the relevant safety level of the overall plant/
machine’s required safety functions, each safety function needs to be considered separ-
ately.
