Pilz PNOZ s30 User Manual

Display menu - Configuration
Operating Manual PNOZ s30
1001715-EN-19
| 70
8.7.4 Settings
Level Designation
on the display
Description Settings
1 Permanent Dis-
play
Default:
Std Min : Sek (sys-
tem time)
v (current speed of
track AB)
Position
Permanent Display
Current values and information
regarding configuration are dis-
played.
You can change the permanent
display on the display
Display combinations:
} vz (current speed of track Z)
} v (current speed of track AB)
} Position
} Switch functions 1 ... 9: F1 ... F9
} v (current speed of track AB)
} Position
} Line 1/2: F1/F2, F3/F2, F5/F4, F7/F6 or
F9/F8
(parameters selected via select inputs).
} v (current speed of track AB)
} Std Min : Sek (system time)
} v (current speed of track AB)
} Position
1 Displ. Units
Speed: Dist: Pos.:
Default:
Hz Imp
Select unit of speed and dis-
tance (position).
Speed: (speed) - Pos. (distance/position)
} Hz Imp (pulse)
} Hz Edg (edge)
} m/s m
} m/min m
} m/h m
} rps rot
} rpm rot
1 Conversion
Default:
1 Hz= 1 Imp/s
Unit conversion.
Enter ratio of unit to pulses.
Display
} 1 Hz= 1 Imp/s
} 1 Hz = 4 Edg/s
} 1 m = x Imp (x = 1 ... 10,000,000 pulses)
} 1 rot = x Imp (x = 1 ... 10,000,000 pulses)
1 Encoder Settings Create encoder configuration
for tracks A, /A, B, /B, Z, /Z, S
