Pilz PNOZ s30 User Manual

Display menu - Configuration
Operating Manual PNOZ s30
1001715-EN-19
| 71
Level Designation
on the display
Description Settings
2 Encoder
Default:
Undefined
Select pre-defined encoder
types for the tracks A, B and Z:
Proximity switch
Encoder
} with and without inverted sig-
nals
} with or without Z-Index (0-In-
dex)
} with proximity switch at track
Z
Note:
If "Undefined" is selected, an er-
ror message is shown when you
confirm the menu
No encoder selected:
} Undefined
Proximity switch (Ini):
} Initiator A: pnp B: pnp
} Initiator A: npn B: pnp
} Initiator A: pnp B: npn
} Initiator A: npn B: npn
} Initiator A/B: pnp r.D. (with reduced dia-
gnostics)
Encoder:
} TTL
– TTL differential (A, /A, B, /B)
– TTL single ended (A, B)
} TTL with Z-Index
} TTL diff. Z index (A, /A, B, /B, Z, /Z)
} TTL single Z index (A, B, Z)
} HTL
– HTL differential (A, /A, B, /B)
– HTL single ended (A, B)
} HTL with Z index
HTL diff. Z index (A, /A, B, /B, Z, /Z)
HTL single Z index (A, B, Z)
} Sin/Cos 1 Vss
– sin/cos 1 Vss (A, /A, B, /B)
} Sin/Cos 1 Vss with Z index
– sin/cos 1 Vss Z Index (A, /A, B, /B, Z, /
Z)
} Hiperface
– Hiperface (A, /A, B, /B)
