Function description
Operating Manual PNOZ s30
1001715-EN-19
| 35
No. On the display Description
15 F2 ∧ F3 F2 AND F3 Logic operations
16 F4 ∧ F5 F4 AND F5
17 F1 ∧ F6-F7 F1 AND F6-F7
18 F1 ∧ F8-F9 F1 AND F8-F9
19 F6 ∨ F7 F6 OR F7
20 F8 ∨ F9 F8 OR F9
21 F1 ∨ F2-F3 F1 OR F2-F3
22 F1 ∨ F4-F5 F1 OR F4-F5
23 0 – 20 mA Ana-
logue
Analogue output
24 4 – 20 mA Ana-
logue
5.4.3 Special functions
In Select mode "1 of 4" or "all 16", additional special functions can be configured in addition
to the switching functions for each parameter set (P0 to P5).
Special functions cannot be configured in the select mode "none".
The following configuration options are available:
} No special function (default)
No special function is performed in the selected parameter set.
} No 2 encoder diagnostics
There is no plausibility check between fAB and fZ. This special function may only be used
when one of the following encoder types in configured:
– HTL single Z Freq. Ini pnp
– TTL single Z Freq. Ini pnp
– TTL differential Z Freq. Ini pnp
– HTL differential Z Freq. Ini pnp
– sin/cos 1 Vss Z Freq. Ini pnp
– Hiperface Z Freq. Ini pnp
For a parameter set with the special function "No 2 encoder diagnostics" the operating
mode without Z Freq. Ini pnp must be used for the safety assessment.
Please note that the "Select inputs mode" setting may reduce the safety level (see under
Select Inputs [ 31]).
