Operating Manual PNOZ s30
1001715-EN-19
| 68
} Hysteresis
Standstill and speed, 2 % each
} Output assignment
– Standstill: Relay output Rel.1 and semiconductor output Out 1
– Speed: Relay output Rel.2 and semiconductor output Out 2
} Start mode
– All outputs: Automatic start ("Automatic")
} Switch delay
None
} Max. encoder frequency
3.5kHz
8.7.3 Basic settings for the rotary encoder
Settings for basic configuration 2
Level Designation
on the display
Description Settings
1 Basic Parameter
Encoder:
Default:
Load?
Select the default settings with
which the basic configuration
menu "Rotary encoder:" is to be
called:
- Load: The basic parameters are
loaded. Then it switches to the ba-
sic menu "Rotary encoder:".
The basic parameters should al-
ways be loaded when commis-
sioning for the first time.
- Edit: The basic parameters are
not loaded, i.e. all parameters are
retained. The basic menu para-
meters can be changed within the
permitted boundaries.
-Escape: Exits the basic menu.
2 Encoder
Default:
TTL differential
Select rotary encoder type -TTL differential (A, /A, B, /B)
-TTL single ended (A, B)
-HTL differential (A, /A, B, /B)
-HTL single ended (A, B)
-sin/cos 1 Vss (A, /A, B, /B)
-Hiperface (A, /A, B, /B)
