Display menu - Configuration
Operating Manual PNOZ s30
1001715-EN-19
| 61
Insert chip
card
1. Data is not written to the chip card
Please insert SIM
Card!
Write con-
figuration to
SIM: No?
Insert rewritable SIM Card!
Do not allow data to be written to the chip card
8.5.3 Read data from chip card
If you are inserting a chip card which has not yet been written by a PNOZ s30, you have the
option to:
Insert chip card (data
on chip card different
from device)
1. 2. Data is read into
the unit
Current
menu
SIM: Name of the
configuration (8
characters)
CRC: 12345 (0 ..
65535)
Load SIM: No?
SIM: Name
of the con-
figuration
(8 charac-
ters)
CRC:
12345 (0 ..
65535)
Load SIM:
Yes?
Current menu
Allow data to be read from the chip card
Note:
After the chip card is loaded, all the outputs are switched off. The device must be restarted
(switch off and on or software restart) to start up again.
Insert chip card (Data on
chip card different from
device)
1. Data is not read into the device, data
is written to the chip card
Current menu SIM: Name of the con-
figuration (8 charac-
ters)
CRC: 12345 (0 .. 65535)
Load SIM: No?
Write configuration to SIM: No?
(for more details see "Write data to
chip card)
Do not allow data to be read from the chip card
