Technical details
Operating Manual PNOZ s30
1001715-EN-19
| 102
12 Technical details
General 750330 751330
Certifications
CCC, CE, EAC, TÜV, UKCA, cU-
Lus Listed
CCC, CE, EAC, TÜV, UKCA, cU-
Lus Listed
Electrical data 750330 751330
Supply voltage
Voltage 24 - 240 V 24 - 240 V
Kind AC/DC AC/DC
Voltage tolerance -15 %/+10 % -15 %/+10 %
Output of external power supply
(AC) 9 VA 9 VA
Output of external power supply
(DC) 5,5 W 5,5 W
Frequency range AC 50 - 60 Hz 50 - 60 Hz
Residual ripple DC 160 % 160 %
Duty cycle 100 % 100 %
External unit fuse protection F1
min. 1 A 1 A
External unit fuse protection F1
max. Max. conductor cross section Max. conductor cross section
Proximity switch input 750330 751330
Number of inputs 2 2
Input signal level
Signal level at "1" 11 - 30 V 11 - 30 V
Signal level at "0" -0,5 - 3 V -0,5 - 3 V
Input resistance 22 kOhm 22 kOhm
Input's frequency range 0 - 1.000 kHz 0 - 1.000 kHz
Configurable monitoring frequency
Without hysteresis 10 mHz - 1.000 kHz 10 mHz - 1.000 kHz
Incremental encoder input 750330 751330
Number of inputs 1 1
Connection type RJ45 female connector, 8-pin RJ45 female connector, 8-pin
Input signal level 0,5 - 30 Vss 0,5 - 30 Vss
Phase position for the differential
signals A, /A and B,/B 90° ±30° 90° ±30°
Overload protection -50 - 65 V -50 - 65 V
Input resistance 20 kOhm 20 kOhm
Input's frequency range 0 - 1.000 kHz 0 - 1.000 kHz
Configurable monitoring frequency
Without hysteresis 10 mHz - 1.000 kHz 10 mHz - 1.000 kHz
Inputs 750330 751330
Voltage at
Start circuit DC 24 V 24 V
Feedback loop DC 24 V 24 V
