Pilz PNOZ s30 User Manual

Technical details
Operating Manual PNOZ s30
1001715-EN-19
| 103
Inputs 750330 751330
Current at
Start circuit DC 5 mA 5 mA
Feedback loop DC 5 mA 5 mA
Max. inrush current impulse
Current pulse, feedback loop 0,06 A 0,06 A
Pulse duration, feedback loop 0,8 ms 0,8 ms
Current pulse, start circuit 0,06 A 0,06 A
Pulse duration, start circuit 0,8 ms 0,8 ms
Reset input 750330 751330
Number 4 4
Low signal -3 - 5 V -3 - 5 V
High signal 15 - 30 V 15 - 30 V
Current 5 mA 5 mA
Analogue outputs 750330 751330
Number of analogue outputs 1 1
Type of analogue outputs Current Current
Output range 0 .. 20 mA, 4 .. 20 mA 0 .. 20 mA, 4 .. 20 mA
Max. open circuit voltage 22 V 22 V
Max. permitted resistive load 500 Ohm 500 Ohm
Typ. processing time of the ana-
logue output 8 ms 8 ms
Accuracy of analogue output 1,5 % (bei 25 °C) 1,5 % (bei 25 °C)
Semiconductor outputs 750330 751330
Number 4 4
Voltage 24 V 24 V
Current 50 mA 50 mA
External supply voltage 24 V 24 V
Voltage tolerance -20 %/+20 % -20 %/+20 %
Residual current at "0" signal 0,5 mA 0,5 mA
Max. internal voltage drop 0,2 V 0,2 V
Conditional rated short circuit cur-
rent 100 A 100 A
Utilisation category in accordance
with EN 60947-1 DC-12 DC-12
Relay outputs 750330 751330
Number of output contacts
Safety contacts (N/O), instant-
aneous 2 2
Auxiliary contacts (N/C) 2 2
Max. short circuit current IK 1 kA 1 kA
Utilisation category
In accordance with the standard EN 60947-4-1 EN 60947-4-1
