Display menu - Configuration
Operating Manual PNOZ s30
1001715-EN-19
| 82
Level Menu designation Description Display/Settings
1 Error Stack Entries Error stack entries
Up to 20 error stack entries are
displayed
See chapter Error stack
entries [ 92]
Further information can be dis-
played by pressing the rotary
knob.
Repairable error:
Level 2:
1st line: Seq. No. "Err.:", error number
2nd + 3rd line: Plain text to describe er-
ror for the user
Level 3:
1st line: Seq. No. "Repairable"
2nd line: "System Time"
3rd line: System time when the error
occurred
Level 4:
Information for Pilz Service
System error:
Level 2:
1st line: Seq. No. "Err.:", error number
2nd line: "System Error"
3rd line: System time when the error
occurred
Level 3:
Information for Pilz Service
1 Safe Error Stack
Entries?
The error list can be saved to the
chip card.
2 Safe Error Stack
Entries:
100%
Appears when the error list is
saved
1 Input Module SW
Version
Va.b
For internal purposes only
1 Main Unit SW Ver-
sion
Va.b
For internal purposes only
8.7.7 Restart
Level Menu designation Description Settings
1 ErrorAcknowledge Restart PNOZ s30
