Display menu - Configuration
Operating Manual PNOZ s30
1001715-EN-19
| 79
Level Menu designation Description Settings
1 Function Hysteresis
2 (F1 ... F9) Function
Hysteresis
Default:
1 %
Enter hysteresis for the switch
functions F1 ... F9
(not effective with position and dir-
ection monitoring)
0 ... 50 %
1 Output Delay Setting for the delay effect and
delay time for the outputs
2 Delay Output
(Rel.1 ... Out 4)
Default:
On 0 ms (display
only)
Setting for the delay time effect
and delay time for the respective
output
3 Delay Effect
(Rel.1 ... Out 4)
Default:
Enter whether the delay time is to
be activated when switching on,
switching off, or switching on and
off.
} Switch-on delay retriggerable
} Switch-off delay retriggerable
} Switch-on switch-off delay retrigger-
able
} Switch-off delay not retriggerable
3 Delay Time
(Rel.1 ... Out 4)
Default:
tdO: 0 ms
Select delay time for the respect-
ive output
0 ... 30.0 s
1 Output Out Logic Setting for the switching direction
of the semiconductor outputs
2 output
(Out 1 ... Out 4)
Logic
Default:
N/O contact
Select the switching direction of
the semiconductor outputs Out
1 ... Select Out 4:
N/O contact (normally energised
mode)
N/C contact (normally de-ener-
gised mode)
} N/O contact
} N/C contact
1 Outputs Synchron-
ous start
Setting for synchronous start
