Function description
Operating Manual PNOZ s30
1001715-EN-19
| 32
"All 16" mode
In this mode, the number of parameter sets can be increased to max.16. This mode can
only be used for applications up to max. PLd of ENISO13849-1 and up to SILCL2 of
ENIEC62061.
Parameter set Signal states of the select inputs
SEL 8 (Y13) SEL 4 (Y12) SEL 2 (Y11) SEL 1 (Y10)
P0 0 0 0 0
P1 0 0 0 1
P2 0 0 1 0
P3 0 0 1 1
P4 0 1 0 0
P5 0 1 0 1
P6 0 1 1 0
P7 0 1 1 1
P8 1 0 0 0
P9 1 0 0 1
P10 1 0 1 0
P11 1 0 1 1
P12 1 1 0 0
P13 1 1 0 1
P14 1 1 1 0
P15 1 1 1 1
When the expanded parameter sets are used, please note the following:
An open circuit when activating the select inputs triggers a switch to a parameter set with a
lower number (e.g. P7→ P3 with open circuit at SEL4).
Limit values for the switch functions should therefore be entered in ascending order (para-
meter set P0 → lowest values, parameter set P15 → highest values).
For this reason, a special function "No 2 encoder diagnostics" should be configured in a
parameter set with a higher number, so that a potential open circuit cannot activate this
function unintentionally.
Delay on the select inputs
A reaction time can be entered for the select inputs. That way it is possible to filter out in-
valid signals (e.g. contact bounce or an intermediate state) that occur when switching. The
new parameter set will be activated only when the delay time has elapsed.
