Create configuration in PNOZsigma Configurator
Operating Manual PNOZ s30
1001715-EN-19
| 89
Transfer project via cable from PNOZs30 to the PNOZsigma Configurator
1. Connect the PNOZ s30 with a free USB interface of your computer. To do this, use the
cable PNOZ s30 USB-configuration-cable which is available at Pilz as an
accessory [ 129].
2. In the PNOZsigma Configurator, click on the start page on the button to download
the configuration to the PNOZ s30.
Please not when downloading from a PNOZ s30 Version 2.2:
When transferring the configuration from a PNOZ s30 with device version 2.2, the CRC
of the PNOZ s30 configuration must be entered into the PNOZsigma Configurator, be-
fore you create the project in PNOZsigma Configurator.
When the download is complete, the configuration is created in PNOZsigma Configurator
as a project.
Replace project in PNOZsigma Configurator
If a project with the same name already exists in the PNOZsigma Configurator, you can
write over the existing project or open the new project and save it under a different name.
By changing the project name, the configuration CRC is also changed.
NOTICE
Please note:
Identical project configurations have the same check sum when the project
name has not been changed.
