Pixsys MCM260X User Manual

Manuale d’uso - MCM260X - 17
4.1.d MCM260X-9AD
1
+
–
12..24 VDC
2
Power supply 12..24Vdc ±15%
1: +Vdc
2: -Vdc
3
-V
4
+V
Power supply for normalized sensors
AI1
+
–
AI
TC
6
5
AI2
9
8
AI3
27
26
AI4
30
29
Analog inputs for thermocouples K, S, R, J, T, E, N, B.
• Respect the polarity
• To avoid extensions use a compensating cable and clips that suit the
thermocouple used (compensating)
AI1 AI2 AI3 AI4
AI
Rosso
Red
Bianco
White
Rosso
Red
PT/NI100
7
5
6
10
8
9
28
26
27
31
29
30
Analog inputs for resistance thermometers PT100, Ni100.
• For the three wire connection use cables with the same section
• For the two wire connection short circuit clips 6 and 7 (AI1), 9 and 10 (AI2),
27 and 28 (AI3), 30 and 31 (AI4).
RED
ROSSO
RED
ROSSO
WHITE
BIANCO
5
7
6
AI1 AI2
10
8
AI3
28
26
AI4
31
29
AI
PTC/NTC
7
5
Analog inputs for resistance thermometers NTC, PTC, PT500, PT1000 and
linear potentiometers.
AI1 AI2 AI3 AI4
+
–
AI
V
mA
6
5
9
8
27
26
30
29
Analog inputs for normalized current and voltage signals.
• Respect the polarity. Power supply of sensor with clips 3 and 4.
11
+
–
V / mA
AO1 AO2
12
32
33
Analog outputs AO1 and AO2
13 14 19.. 20
I/Q.1 I/Q.2 I/Q.7 I/Q.8
12..24 VDC
Digital inputs PNP 24Vdc / Static outputs 24Vdc
13: Input / Output 1
14: Input / Output 2
15: Input / Output 3
16: Input / Output 4
17: Input / Output 5
18: Input / Output 6
19: Input / Output 7
20: Input / Output 8
21
+VDC
12..24 VDC
Positive for power supply of static outputs 1..8
34 35 40.. 41
I/Q.9 I/Q.10 I/Q.15 I/Q.16
12..24 VDC
Digital inputs PNP 24Vdc / Static outputs 24Vdc
34: Input / Output 9
35: Input / Output 10
36: Input / Output 11
37: Input / Output 12
38: Input / Output 13
39: Input / Output 14
40: Input / Output 15
41: Input / Output 16
42
+VDC
12..24 VDC
Positive for power supply of static outputs 9..16
