Pixsys MCM260X User Manual

Manuale d’uso - MCM260X - 41
Modbus
address
Description
Read
Write
Reset
value
1000
1050
Digital input status
It contains the logic status of the digital inputs:
Bit 0: Input 1
Bit 1: Input 2
Bit 2: Input 3
Bit 3: Input 4
Bit 4: Input 5
Bit 5: Input 6
Bit 6: Input 7
Bit 7: Input 8
Bit 8: Input 9
Bit 9: Input 10
Bit 10: Input 11
Bit 11: Input 12
Bit 12: Input 13
Bit 13: Input 14
Bit 14: Input 15
Bit 15: Input 16
RO
1001
1051
AI1 analog input value RO
1002
1052
AI2 analog input value RO
1003
1053
AI3 analog input value RO
1004
1054
AI4 analog input value RO
1005
1056
Encoder/Counter calculations no. 1 H
Most significant word of the double-word that contains the calculations
of encoder/counter no. 1
RO
1006
1055
Encoder/Counter calculations no. 1 L
Least significant word of the double-word that contains the calculations
of encoder/counter no. 1
RO
1007
1058
Encoder/Counter calculations no. 2 H
Most significant word of the double-word that contains the calculations
of encoder/counter no. 2
RO
1008
1057
Encoder/Counter calculations no. 2 L
Least significant word of the double-word that contains the calculations
of encoder/counter no. 2
RO
1009
1060
Encoder/Counter calculations no. 3 H
Most significant word of the double-word that contains the calculations
of encoder/counter no. 3
RO
1010
1059
Encoder/Counter calculations no. 3 L
Least significant word of the double-word that contains the calculations
of encoder/counter no. 3
RO
1011
1062
Encoder/Counter calculations no. 4 H
Most significant word of the double-word that contains the calculations
of encoder/counter no. 4
RO
1012
1061
Encoder/Counter calculations no. 4 L
Least significant word of the double-word that contains the calculations
of encoder/counter no. 4
RO
