User’s Manual of FGSD-1022 Series
127
number.
TCP
Set this field if Packet Type is IPv4, else ignore.
Any / FTP(21) / HTTP(80)
Any
Port
Set this field if Packet Type is IPv4, else ignore.
0~65535
If TCP port not find in TCP field, you can direct assign number.
UDP
Set this field if Packet Type is IPv4, else ignore.
Any / DHCP(67) / TFTP(69) / NetBios(137)
Any
Port
Set this field if Packet Type is IPv4, else ignore.
0~65535
If UDP port not find in UDP field, you can direct assign number.
Port Id
Source port id, from 1~10, 0 means don’t care. 0
Current List
You create ACL and Binding groups.
 Non-IPv4 ACL
In ※Packet Type / Binding box should select ※Non-IPv4
Object Description Default Vaule
Group ID
1 ~ 220 (max. 220ACL group)
Action
Permit / Deny.
 Permit: Permit packet cross switch.
 Deny: Drop packet.
Permit
VLAN
Any / VID.
 Any: Any VLAN ID.
 VID: 1~4094. A certain VLAN ID.
Any
Packet Type
IPv4 / Non-IPv4 / Binding
 IPv4: Set Ipv4 packet field.
 Non-IPv4: Set non-Ipv4 packet field.
 Binding: Set binding entry.
IPv4
Ether Type
Set this field if Packet Type is Non-IPv4, else ignore.)
Any / ARP(0x0806) / IPX(0x8137)
Any
Type
Set this field if Packet Type is Non-IPv4, else ignore.)
0~0xFFFF
If ether type not find in Ether Type field, you can direct assign
number.
Current List
You create ACL and Binding groups.
