Object Description
 VLAN User
A VLAN User is a module that uses services of the VLAN management
functionality to configure VLAN memberships and VLAN port configuration such
as PVID, UVID. Currently we support following VLAN :
- Admin : This is reffered as static.
- NAS : NAS provides port-based authentication, which involves
communications between a Supplicant, Authenticator, and an Authentication
Server.
- Voice VLAN : Voice VLAN is a VLAN configured specially for voice traffic
typically originating from IP phones.
- MVR : MVR is used to eliminate the need to duplicate multicast traffic for
subscribers in each VLAN. Multicast traffic for all channels is sent only on a
single (multicast) VLAN.
 Port Members
A row of check boxes for each port is displayed for each VLAN ID.
If a port is included in a VLAN, an image
will be displayed.
If a port is included in a Forbidden port list, an image
will be displayed.
If a port is included in a Forbidden port list and dynamic VLAN user register
VLAN on same Forbidden port, then conflict port will be displayed as conflict port.
The VLAN Membership
Status Page shall show the current VLAN port members
for all VLANs configured by a selected VLAN User (selection shall be allowed by
a Combo Box). When ALL VLAN Users are selected, it shall show this
information for all the VLAN Users, and this is by default. VLAN membership
allows the frames classified to the VLAN ID to be forwarded on the respective
VLAN member ports.
 VLAN Membership
Buttons
: Select VLAN Users from this drop down list.
Auto-refresh
: Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the Page immediately.
: Updates the table starting from the first entry in the VLAN Table, i.e. the entry with the lowest VLAN ID.
: Updates the table, starting with the entry after the last entry currently displayed.
