Planet IGS-20040MT User Manual

User’s Manual of IGS-20040MT
 Up to 16Gbps bandwidth(duplex mode)
 Provides port mirror (many-to-1)
 Port Mirroring of the incoming or outgoing traffic on a particular port
 Loop protection to avoid broadcast loops
 Supports E.R.P.S. (Ethernet Ring Protection Switching)
 IEEE 1588 and Synchronous Ethernet network timing
 Quality of Service
 Ingress Shaper and Egress Rate Limit per port bandwidth control
 8 priority queues on all switch ports
 Traffic classification
- IEEE 802.1p CoS
- IP TOS / DSCP / IP Precedence
- IP TCP/UDP port number
- Typical network application
 Strict priority and Weighted Round Robin (WRR) CoS policies
 Supports QoS and In/Out bandwidth control on each port
 Traffic-policing policies on the switch port
 DSCP remarking
 Multicast
 Supports IPv4 IGMP Snooping v1, v2 and v3
 Supports IPv6 MLD Snooping v1 and v2
 Querier mode support
 IGMP Snooping port filtering
 MLD Snooping port filtering
 MVR (Multicast VLAN Registration)
 Security
 Authentication
 IEEE 802.1x Port-based / MAC-based network access authentication
 Built-in RADIUS client to cooperate with the RADIUS servers
 TACACS+ login users access authentication
 RADIUS / TACACS+ users access authentication
 Access Control List
 IP-based Access Control List (ACL)
 MAC-based Access Control List
 Source MAC / IP address binding
 DHCP Snooping to filter un-trusted DHCP messages
 Dynamic ARP Inspection discards ARP packets with invalid MAC address to IP address binding
 IP Source Guard prevents IP spoofing attacks
 Auto DoS rule to defend DoS attack
 IP address access management to prevent unauthorized intruder
 Layer 3 IP Routing Features
 Supports maximum 128 static routes and route summarization
17

Planet IGS-20040MT Specifications

General

Switch type	Managed
Switch layer	L2+
Traffic classification	Yes
Console port	RJ-45
Fiber optic connector	MiniGBIC
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4095
Networking standards	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Stackable	-
Certification	FCC, CE
Product color	Blue, White
Housing material	Aluminum
International Protection (IP) code	IP30
Fiber ethernet cabling technology	100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput	29.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Number of IP interfaces	8
Power consumption (max)	17 W
Power consumption (typical)	8 W
Heat dissipation	27 BTU/h
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	IPv4 / IPv6
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered	255
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107.3 mm
Width	76.8 mm
Height	152 mm
Weight	1043 g
