User’s Manual of IGS-20040MT
170
 Unregistered IPMCv4
Flooding Enabled
Enable unregistered IPMCv4 traffic flooding.
The flooding control takes effect only when IGMP Snooping is enabled.
When IGMP Snooping is disabled, unregistered IPMCv4 traffic flooding is always
active in spite of this setting.
SSM (Source-Specific Multic
ast) Range allows the SSM-aware hosts and routers
run the SSM service model for the groups in the address range.
 IGMP SSM Range
Enable IGMP Leave Pro
xy. This feature can be used to avoid forwarding
unnecessary leave messages to the router side.
 Leave Proxy Enable
 Proxy Enable
Enable IGMP Proxy. This feature can be used to avoid forwarding unnecessary
join and leave messages to the router side.
 Router Port
Specify which ports act as IGMP router ports. A router port is a port on the
Ethernet switch that leads towards the Layer 3 multicast device or IGMP querier.
The Switch forwards IGMP join or leave packets to an IGMP router port.
 Auto:
Select “Auto” to have the Industrial Managed Switch automatically
uses the port as IGMP Router port if the port receives IGMP query
packets.
 Fix:
The Industrial Managed Switch always uses the specified port as an
IGMP Router port. Use this mode when you connect an IGMP
multicast server or IP camera which applied with multicast protocol to
the port.
 None:
The Industrial Managed Switch will not use the specified port as an
IGMP Router port. The Industrial Managed Switch will not keep any
record of an IGMP router being connected to this port. Use this mode
when you connect other IGMP multicast servers directly on the
non-querier Industrial Managed Switch and don’t want the multicast
stream be flood to uplink switch throught the port that connected to
the IGMP querier.
Enable the fast leave o
n the port.
 Fast Leave
Enable to limit the numb
er of multicast groups to which a switch port can belong.
 Throtting
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.

Planet IGS-20040MT Specifications

General

Switch type	Managed
Switch layer	L2+
Traffic classification	Yes
Console port	RJ-45
Fiber optic connector	MiniGBIC
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4095
Networking standards	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Stackable	-
Certification	FCC, CE
Product color	Blue, White
Housing material	Aluminum
International Protection (IP) code	IP30
Fiber ethernet cabling technology	100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput	29.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Number of IP interfaces	8
Power consumption (max)	17 W
Power consumption (typical)	8 W
Heat dissipation	27 BTU/h
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	IPv4 / IPv6
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered	255
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107.3 mm
Width	76.8 mm
Height	152 mm
Weight	1043 g
