Planet IGS-20040MT User Manual

User’s Manual of IGS-20040MT
195
All means all ports will have one specific setting.
 DPL
Controls the default drop precedence level.
All frames are classified to a drop precedence level.
If the port is VLAN aware and the frame is tagged, then the frame is classified to
a DPL that is equal to the DEI value in the tag. Otherwise the frame is classified
to the default DPL. The classified DPL can be overruled by a QCL entry.
All means all ports will have one specific setting.
 PCP
Controls the default PCP
value. All frames are classified to a PCP value.
If the port is VLAN aware and the frame is tagged, then the frame is classified to
the PCP value in the tag. Otherwise the frame is classified to the default PCP
value.
All means all ports will have one specific setting.
 DEI
Controls the default DEI
value. All frames are classified to a DEI value.
If the port is VLAN aware and the frame is tagged, then the frame is classified to
the DEI value in the tag. Otherwise the frame is classified to the default DEI
value.
All means all ports will have one specific setting.
 Tag Class.
Shows the classification mode for tagged frames on this port.
 Disabled: Use default CoS and DPL for tagged frames.
 Enabled: Use mapped versions of PCP and DEI for tagged frames.
Click on the mode in order to configure the mode and/or mapping.
Note: This setting has no effect if the port is VLAN unaware. Tagged frames
received on VLAN unaware ports are always classified to the default CoS and
DPL.
Click to Enable
DSCP Based QoS Ingress Port Classification.
 DSCP Based
 Address Mode
The IP/MAC address mode specifying whether the QCL
classification must be
based on source (SMAC/SIP) or destination (DMAC/DIP) addresses on this port.
The allowed values are:
 Source: Enable SMAC/SIP matching.
 Destination: Enable DMAC/DIP matching.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.

Planet IGS-20040MT Specifications

General

Switch type	Managed
Switch layer	L2+
Traffic classification	Yes
Console port	RJ-45
Fiber optic connector	MiniGBIC
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4095
Networking standards	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Stackable	-
Certification	FCC, CE
Product color	Blue, White
Housing material	Aluminum
International Protection (IP) code	IP30
Fiber ethernet cabling technology	100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput	29.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Number of IP interfaces	8
Power consumption (max)	17 W
Power consumption (typical)	8 W
Heat dissipation	27 BTU/h
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	IPv4 / IPv6
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered	255
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107.3 mm
Width	76.8 mm
Height	152 mm
Weight	1043 g
