User’s Manual of IGS-20040MT
The default value is "kbps".
 Queue Shaper Excess
Controls whether the queue is allowed to use excess bandwidth.
 Queue Scheduler
Weight
Controls the weight for this queue.
This value is restricted to 1-100. This parameter is only shown if "Scheduler
Mode" is set to "Weighted".
The default value is "17".
Shows the
weight in percent for this queue. This parameter is only shown if
"Scheduler Mode" is set to "Weighted".
 Queue Scheduler
Percent
Controls w
hether the port shaper is enabled for this switch port.
 Port Shaper Enable
 Port Shaper Rate
Controls the rate for the port shaper.
This value is restricted to 100-1000000 when the "Unit" is "kbps", and it is
restricted to 1-13200 when the "Unit" is "Mbps".
The default value is 500.
 Port Shaper Unit
Controls the unit of measure for the port shaper rate as "kbps" or "Mbps".
The default value is "kbps".
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
: Click to undo any changes made locally and return to the previous Page.
199

Planet IGS-20040MT Specifications

General

Switch type	Managed
Switch layer	L2+
Traffic classification	Yes
Console port	RJ-45
Fiber optic connector	MiniGBIC
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4095
Networking standards	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Stackable	-
Certification	FCC, CE
Product color	Blue, White
Housing material	Aluminum
International Protection (IP) code	IP30
Fiber ethernet cabling technology	100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput	29.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Number of IP interfaces	8
Power consumption (max)	17 W
Power consumption (typical)	8 W
Heat dissipation	27 BTU/h
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	IPv4 / IPv6
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered	255
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107.3 mm
Width	76.8 mm
Height	152 mm
Weight	1043 g
