Planet IGS-20040MT User Manual

User’s Manual of IGS-20040MT
3. LLC
4. SNAP
5. IPv4
6. IPv6
Note: all frame types are explained below.
Allow all
types of frames.
 Any
Ethernet Type Valid ethernet type can have value within 0x600-0xFFFF or 'Any'
but excluding 0x800(IPv4) and 0x86DD(IPv6), default value is 'Any'.
 EtherT
ype
 LLC
■ SSAP Address Valid SSAP(Source Service Access Point) can vary from
0x00 to 0xFF or 'Any', the default value is 'Any'
■ DSAP Address Valid DSAP(Destination Service Access Point) can vary
from 0x00 to 0xFF or 'Any', the default value is 'Any'
■ Control Address Valid Control Address can vary from 0x00 to 0xFF or
'Any', the default value is 'Any'
PID Valid PID(a.k.a ethernet type) can have value within 0x00-0xFFFF or 'Any',
default value is 'Any'
 SN
AP
 IPv4
■ Protocol IP protocol number: (0-255, TCP or UDP) or 'Any'
■ Source IP Specific Source IP address in value/mask format or 'Any'. IP and
Mask are in the format x.y.z.w where x, y, z, and w are decimal numbers
between 0 and 255. When Mask is converted to a 32-bit binary string and
read from left to right, all bits following the first zero must also be zero
■ DSCP Diffserv Code Point value(DSCP): It can be specific value, range of
value or 'Any'. DSCP values are in the range 0-63 including BE, CS1-CS7,
EF or AF11-AF43
■ IP Fragment IPv4 frame fragmented option: yes|no|any
■ Sport Source TCP/UDP port:(0-65535) or 'Any', specific or port range
applicable for IP protocol UDP/TCP
■ Dport Destination TCP/UDP port:(0-65535) or 'Any', specific or port range
applicable for IP protocol UDP/TCP
 IPv6
■ Protocol IP protocol number: (0-255, TCP or UDP) or 'Any'
■ Source IP IPv6 source address: (a.b.c.d) or 'Any', 32 LS bits
■ DSCP Diffserv Code Point value(DSCP): It can be specific value, range of
value or 'Any'. DSCP values are in the range 0-63 including BE, CS1-CS7,
210

Planet IGS-20040MT Specifications

General

Switch type	Managed
Switch layer	L2+
Traffic classification	Yes
Console port	RJ-45
Fiber optic connector	MiniGBIC
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4095
Networking standards	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Stackable	-
Certification	FCC, CE
Product color	Blue, White
Housing material	Aluminum
International Protection (IP) code	IP30
Fiber ethernet cabling technology	100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput	29.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Number of IP interfaces	8
Power consumption (max)	17 W
Power consumption (typical)	8 W
Heat dissipation	27 BTU/h
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	IPv4 / IPv6
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered	255
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107.3 mm
Width	76.8 mm
Height	152 mm
Weight	1043 g
