The secret key - up to 63 char
acters long - shared between the RADIUS server
and the switch.
 Key
The IPv4 address to be used
as attribute 4 in RADIUS Access-Request packets.
If this field is left blank, the IP address of the outgoing interface is used.
 NAS-IP-Address
The IPv6 address to be used
as attribute 95 in RADIUS Access-Request
packets. If this field is left blank, the IP address of the outgoing interface is used.
 NAS-IPv6-Address
The identifier - up to 253 char
acters long - to be used as attribute 32 in RADIUS
Access-Request packets. If this field is left blank, the NAS-Identifier is not
included in the packet.
 NAS-Identifier
Server Configuration
The table has one row for each RADIUS Server and a number of columns, which are:
Object Description
To delete a RADIUS server en
try, check this box. The entry will be deleted during
the next Save.
 Delete
The IP address or hostname
of the RADIUS server.
 Hostname
The UDP port to use on the R
ADIUS server for authentication.
 Auth Port
The UDP port to use on the R
ADIUS server for accounting.
 Acct Port
This optional s
etting overrides the global timeout value. Leaving it blank will use
the global timeout value.
 Timeout
This optional s
etting overrides the global retransmit value. Leaving it blank will
use the global retransmit value.
 Retransmit
This optional s
etting overrides the global key. Leaving it blank will use the global
key.
 Key
Buttons
: Click to add a new RADIUS server. An empty row is added to the table, and the RADIUS
server can be configured as needed. Up to 5 servers are supported.
: Click to undo the addition of the new server.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
260

Planet IGS-20040MT Specifications

General

Switch type	Managed
Switch layer	L2+
Traffic classification	Yes
Console port	RJ-45
Fiber optic connector	MiniGBIC
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4095
Networking standards	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Stackable	-
Certification	FCC, CE
Product color	Blue, White
Housing material	Aluminum
International Protection (IP) code	IP30
Fiber ethernet cabling technology	100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput	29.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Number of IP interfaces	8
Power consumption (max)	17 W
Power consumption (typical)	8 W
Heat dissipation	27 BTU/h
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	IPv4 / IPv6
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered	255
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107.3 mm
Width	76.8 mm
Height	152 mm
Weight	1043 g
