User’s Manual of IGS-20040MT
Rx
Access
Accepts
radiusAuthClientExtA
ccessAccepts
The number of RADIUS
Access-Accept packets (valid
or invalid) received from the
server.
Rx
Access Rejects
radiusAuthClientExtA
ccessRejects
The number of RADIUS
Access-Reject packets (valid
or invalid) received from the
server.
Rx
Access
Challenges
radiusAuthClientExtA
ccessChallenges
The number of RADIUS
Access-Challenge packets
(valid or invalid) received from
the server.
Rx
Malformed
Access
Responses
radiusAuthClientExt
MalformedAccessRe
sponses
The number of malformed
RADIUS Access-Response
packets received from the
server. Malformed packets
include packets with an invalid
length. Bad authenticators or
Message Authenticator
attributes or unknown types
are not included as malformed
access responses.
Rx
Bad
Authenticators
radiusAuthClientExtB
adAuthenticators
The number of RADIUS
Access-Response packets
containing invalid
authenticators or Message
Authenticator attributes
received from the server.
Rx
Unknown
Types
radiusAuthClientExtU
nknownTypes
The number of RADIUS
packets that were received
from the server on the
authentication port and
dropped for some other
reason.
Rx
Packets
Dropped
radiusAuthClientExtP
acketsDropped
The number of RADIUS
packets that were received
from the server on the
265

Planet IGS-20040MT Specifications

General

Switch type	Managed
Switch layer	L2+
Traffic classification	Yes
Console port	RJ-45
Fiber optic connector	MiniGBIC
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4095
Networking standards	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Stackable	-
Certification	FCC, CE
Product color	Blue, White
Housing material	Aluminum
International Protection (IP) code	IP30
Fiber ethernet cabling technology	100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput	29.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Number of IP interfaces	8
Power consumption (max)	17 W
Power consumption (typical)	8 W
Heat dissipation	27 BTU/h
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	IPv4 / IPv6
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered	255
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107.3 mm
Width	76.8 mm
Height	152 mm
Weight	1043 g
