User’s Manual of IGS-20040MT
in question.
State
- Shows the state of the server. It takes one of the
following values:
 Disabled: The selected server is disabled.
 Not Ready: The server is enabled, but IP
communication is not yet up and running.
 Ready: The server is enabled, IP communication
is up and running, and the RADIUS module is
ready to accept access attempts.
 Dead (X seconds left): Access attempts were
made to this server, but it did not reply within the
configured timeout. The server has temporarily
been disabled, but will get re-enabled when the
dead-time expires. The number of seconds left
before this occurs is displayed in parentheses.
This state is only reachable when more than one
server is enabled.
Round-Trip
Time
radiusAuthClient
ExtRoundTripTim
e
The time interval (measured in milliseconds) between
the most recent Access-Reply/Access-Challenge and
the Access-Request that matched it from the RADIUS
authentication server. The granularity of this
measurement is 100 ms. A value of 0 ms indicates
that there hasn't been round-trip communication with
the server yet.
RADIUS Accounting Statistics
The statistics map closely to those specified in RFC4670 - RADIUS Accounting Client MIB. Use the server select box to switch
between the backend servers to show details for.
Object Description
RADIUS accounting server packet counter. There are five receive and four transmit
counters.
Direction Name RFC4670 Name Description
 Packet Counters
Rx
Responses
radiusAccClientExt
Responses
The number of RADIUS
packets (valid or invalid)
received from the server.
267

Planet IGS-20040MT Specifications

General

Switch type	Managed
Switch layer	L2+
Traffic classification	Yes
Console port	RJ-45
Fiber optic connector	MiniGBIC
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4095
Networking standards	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Stackable	-
Certification	FCC, CE
Product color	Blue, White
Housing material	Aluminum
International Protection (IP) code	IP30
Fiber ethernet cabling technology	100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput	29.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Number of IP interfaces	8
Power consumption (max)	17 W
Power consumption (typical)	8 W
Heat dissipation	27 BTU/h
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	IPv4 / IPv6
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered	255
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107.3 mm
Width	76.8 mm
Height	152 mm
Weight	1043 g
