User’s Manual of IGS-20040MT
338
The best estimate of the tota
l number of collisions on this Ethernet segment.
Coll.
The tota
l number of packets (including bad packets) received that were 64 octets
in length.
64 Bytes
The tota
l number of packets (including bad packets) received that were between
65 to 127 octets in length.
65~127
The tota
l number of packets (including bad packets) received that were between
128 to 255 octets in length.
128~255
The tota
l number of packets (including bad packets) received that were between
256 to 511 octets in length.
256~511
The tota
l number of packets (including bad packets) received that were between
512 to 1023 octets in length.
512~1023
The tota
l number of packets (including bad packets) received that were between
1024 to 1518 octets in length.
1024~1518
Buttons
: Click to refresh the Page immediately.
Auto-refresh
: Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
: Updates the table, starting from the first entry in the Alarm Table, i.e. the entry with the lowest ID.
: Updates the table, starting with the entry after the last entry currently displayed.
