Planet IGS-20040MT User Manual

User’s Manual of IGS-20040MT
 Slave Only - clock's Device Type is Slave Only
Static member: defined
by the system, true if two-step Sync events and
Pdelay_Resp events are used.
 2 Step Flag
It shows un
ique clock identifier.
 Clock Identity
 One Way
If true, one-way measurements are used. This parameter applies only to a slave.
In one-way mode no delay measurements are performed, i.e. this is applicable
only if frequency synchronization is needed. The master always responds to
delay requests.
 Protocol
Transport protocol used by the PTP protocol engine
ethernet PTP over Ethernet multicast
ip4multi PTP over IPv4 multicast
ip4uni PTP over IPv4 unicast
Note : IPv4 unicast protocol only works in Master only and Slave only clocks
See parameter Device Type
In a unicast Slave only clock you also need configure which master clocks
to request Announce and Sync messages from. See: Unicast Slave configuration
 VLAN Tag
Enable
Enables the VLAN tagging for the PTP frames.
Note: Packets are only tagged if the port is configured for vlan tagging.
i.e:
Port Type != Unaware and PortVLAN mode == None, and the port is member of
the VLAN.
VLAN Identifier
used for tagging the PTP frames.
 VID
Priority
Code Point value used for PTP frames.
 PCP
Buttons
: Click to create a new clock instance.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
Local Clock Current Time
Object Description
Shows the act
ual PTP time with nanosecond resolution.
 PTP Time
Shows the act
ual clock adjustment method. The method depends on the
available hardware.
 Clock Adjustment
Method
 Synchronize to System
Activate this button to synchronize the System Clock to PTP Time.
340

Planet IGS-20040MT Specifications

General

Switch type	Managed
Switch layer	L2+
Traffic classification	Yes
Console port	RJ-45
Fiber optic connector	MiniGBIC
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4095
Networking standards	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Stackable	-
Certification	FCC, CE
Product color	Blue, White
Housing material	Aluminum
International Protection (IP) code	IP30
Fiber ethernet cabling technology	100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput	29.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Number of IP interfaces	8
Power consumption (max)	17 W
Power consumption (typical)	8 W
Heat dissipation	27 BTU/h
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	IPv4 / IPv6
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered	255
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107.3 mm
Width	76.8 mm
Height	152 mm
Weight	1043 g
