User’s Manual of IGS-20040MT
Priority
Code Point value used for PTP frames.
 PCP
Clock current Data Set
Object Description
Steps Removed : It is the number of PT
P clocks traversed from the grandmaster
to the local slave clock.
 stpRm
Time difference bet
ween the master clock and the local slave clock, measured in
ns.
 Offset from master
The mean propagati
on time for the link between the master and the local slave
 Mean Path Delay
Clock Parent Data Set
Object Description
Clock ide
ntity for the parent clock, if the local clock is not a slave, the value is the
clocks own id.
 Parent Port Identity
Port Id for the parent master port
 Port
Parents Stats (alwa
ys false).
 P Stat
It is observed parent offset scale
d log variance
 Var
Observed Parent Clock Phas
e Change Rate. i.e. the slave clocks rate offset
compared to the master. (unit = ns per s).
 Change Rate
 Grand Master Identity
Clock identity for the grand master clock, if the local clock is not a slave, the
value is the clocks own id.
The clock qualit
y announced by the grand master (See description of Clock
Default DataSet:Clock Quality)
 Grand Master Clock
Quality
Clock priorit
y 1 announced by the grand master
 Pri1
Clock priorit
y 2 announced by the grand master
 Pri2
Servo Parameters
Object Description
If true then Offset From Master, MeanPathDelay and clockA
djustment are logged
on the debug terminal
 Display
If true the P part of the algorithm is include
d
 P-enable
If true the I part of the algorithm
is included
 I-enable
 D-enable
If true the D part of the algorithm is included
342

Planet IGS-20040MT Specifications

General

Switch type	Managed
Switch layer	L2+
Traffic classification	Yes
Console port	RJ-45
Fiber optic connector	MiniGBIC
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4095
Networking standards	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Stackable	-
Certification	FCC, CE
Product color	Blue, White
Housing material	Aluminum
International Protection (IP) code	IP30
Fiber ethernet cabling technology	100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput	29.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Number of IP interfaces	8
Power consumption (max)	17 W
Power consumption (typical)	8 W
Heat dissipation	27 BTU/h
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	IPv4 / IPv6
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered	255
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107.3 mm
Width	76.8 mm
Height	152 mm
Weight	1043 g
