User’s Manual of IGS-20040MT
See help on
MEP create WEB.
Tagged VID
See help on
MEP create WEB.
This MAC
Instance Configuration:
Object Description
Level
See help on MEP create WEB.
Format
This is the configuration of the two possible Maintenance Association Identifier
formats.
ITU ICC: This is defined by ITU. 'ICC' can be max. 6 char. 'MEG id' can be max. 7
char.
IEEE String: This is defined by IEEE. 'Domain Name' can be max. 8 char. 'MEG
id' can be max. 8 char.
This is either ITU ICC (MEG ID value[1-6]) or IEEE Maintenance Domain
Name -
depending on 'Format'. See 'Format'.
Domain Name
This is either IT
U UMC (MEG ID value[7-13]) or IEEE Short MA Name -
depending on 'Format'. See 'Format'. In case of ITU ICC format this can be max.
7 char. If only 6 char. is entered the MEG ID value[13] will become NULL.
MEG Id
This value
will become the transmitted two byte CCM MEP ID.
MEP Id
Fault Cause in
dicating that a CCM is received with a lower level than the
configured for this MEP.
cLevel
Fault Cause in
dicating that a CCM is received with a MEG ID different from
configured for this MEP.
cMEG
Fault Cause in
dicating that a CCM is received with a MEP ID different from all
'Peer MEP ID' configured for this MEP.
cMEP
Fault Cause in
dicating that AIS PDU is received.
cAIS
Fault Cause in
dicating that LCK PDU is received.
cLCK
Fault Cause in
dicating that server layer is indicating Signal Fail.
cSSF
The conseque
nt action of blocking service frames in this flow is active.
aBLK
The consequent action of indi
cating Trail Signal Fail to-wards protection is active.
aTSF
This box is use
d to mark a Peer MEP for deletion in next Save operation.
Delete
This value
will become an expected MEP ID in a received CCM - see 'cMEP'.
Peer MEP ID
Unicast Peer MAC
This MAC will be used when unicast is selected with this peer MEP. Also this
MAC is used to create HW checking of receiving CCM PDU (LOC detection) from
this MEP.
347
