Planet IGS-20040MT User Manual

User’s Manual of IGS-20040MT
Instance St
ate:
Object Description
 Protection State
ERPS state according to State Transition Tables in G.8032.
 Port 0
OK: State of East port is ok
SF: State of East port is Signal Fail
 Port 1
OK: State of West port is ok
SF: State of West port is Signal Fail
The transmitted APS accordi
ng to State Transition Tables in G.8032.
 Transmit APS
The received A
PS on Port 0 according to State Transition Tables in G.8032.
 Port 0 Receive APS
The received A
PS on Port 1 according to State Transition Tables in G.8032.
 Port 1 Receive APS
Remaini
ng WTR timeout in milliseconds.
 WTR Remaining
APS is received on the wo
rking flow.
 RPL Un-blocked
RAPS PDU is not received from the other end.
 No APS Received
Block status for Port 0 (Both traffic and R-AP
S block status). R-APS channel is
never blocked on sub-rings without virtual channel.
 Port 0 Block Status
Block status for Port 1 (Both traffic and R-AP
S block status). R-APS channel is
never blocked on sub-rings without virtual channel.
 Port 1 Block Status
Failure
of Protocol Defect(FOP) status. If FOP is detected, red LED glows; else
green LED glows.
 FOP Alarm
Buttons
: Click to save changes.
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs every 6 seconds.
: Click to refresh the page immediately.
: Click to undo any changes made locally and revert to previously saved values.
353

Planet IGS-20040MT Specifications

General

Switch type	Managed
Switch layer	L2+
Traffic classification	Yes
Console port	RJ-45
Fiber optic connector	MiniGBIC
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4095
Networking standards	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Stackable	-
Certification	FCC, CE
Product color	Blue, White
Housing material	Aluminum
International Protection (IP) code	IP30
Fiber ethernet cabling technology	100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput	29.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Number of IP interfaces	8
Power consumption (max)	17 W
Power consumption (typical)	8 W
Heat dissipation	27 BTU/h
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	IPv4 / IPv6
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered	255
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107.3 mm
Width	76.8 mm
Height	152 mm
Weight	1043 g
