Planet IGS-20040MT User Manual

User’s Manual of IGS-20040MT
MFB-FB20 100 WDM(LC) Single Mode 20km 1550nm 1310nm 0 ~ 60 ℃
MFB-TFA20 100 WDM(LC) Single Mode 20km 1310nm 1550nm -40 ~ 75 ℃
MFB-TFB20 100 WDM(LC) Single Mode 20km 1550nm 1310nm -40 ~ 75 ℃
MFB-TFA40 100 WDM(LC) Single Mode 40km 1310nm 1550nm -40 ~ 75 ℃
MFB-TFB40 100 WDM(LC) Single Mode 40km 1550nm 1310nm -40 ~ 75 ℃
Gigabit Ethernet Transceiver (1000Base-X SFP)
Model Speed (Mbps)
Connector
Interface
Fiber Mode Distance Wavelength (nm) Operating Temp.
MGB-GT 1000 Copper -- 100m -- 0 ~ 60 ℃
MGB-SX 1000 LC Multi Mode 550m 850nm 0 ~ 60 ℃
MGB-SX2 1000 LC Multi Mode 2km 1310nm 0 ~ 60 ℃
MGB-LX 1000 LC Single Mode 10km 1310nm 0 ~ 60 ℃
MGB-L30 1000 LC Single Mode 30km 1310nm 0 ~ 60 ℃
MGB-L50 1000 LC Single Mode 50km 1550nm 0 ~ 60 ℃
MGB-L70 1000 LC Single Mode 70km 1550nm 0 ~ 60 ℃
MGB-L120 1000 LC Single Mode 120km 1550nm 0 ~ 60 ℃
MGB-TSX 1000 LC Multi Mode 550m 850nm -40 ~ 75 ℃
MGB-TLX 1000 LC Single Mode 10km 1310nm -40 ~ 75 ℃
MGB-TL30 1000 LC Single Mode 30km 1310nm -40 ~ 75 ℃
MGB-TL70 1000 LC Single Mode 70km 1550nm -40 ~ 75 ℃
Gigabit Ethernet Transceiver (1000Base-BX, Single Fiber Bi-Directional SFP)
Model Speed (Mbps)
Connector
Interface
Fiber Mode Distance Wavelength (TX) Wavelength (RX) Operating Temp.
MGB-LA10 1000 WDM(LC) Single Mode 10km 1310nm 1550nm 0 ~ 60 ℃
MGB-LB10 1000 WDM(LC) Single Mode 10km 1550nm 1310nm 0 ~ 60 ℃
MGB-LA20 1000 WDM(LC) Single Mode 20km 1310nm 1550nm 0 ~ 60 ℃
MGB-LB20 1000 WDM(LC) Single Mode 20km 1550nm 1310nm 0 ~ 60 ℃
MGB-LA40 1000 WDM(LC) Single Mode 40km 1310nm 1550nm 0 ~ 60 ℃
MGB-LB40 1000 WDM(LC) Single Mode 40km 1550nm 1310nm 0 ~ 60 ℃
MGB-LA60 1000 WDM(LC) Single Mode 60km 1310nm 1550nm 0 ~ 60 ℃
MGB-LB60 1000 WDM(LC) Single Mode 60km 1550nm 1310nm 0 ~ 60 ℃
MGB-TLA10 1000 WDM(LC) Single Mode 10km 1310nm 1550nm -40 ~ 75 ℃
MGB-TLB10 1000 WDM(LC) Single Mode 10km 1550nm 1310nm -40 ~ 75 ℃
MGB-TLA20 1000 WDM(LC) Single Mode 20km 1310nm 1550nm -40 ~ 75 ℃
MGB-TLB20 1000 WDM(LC) Single Mode 20km 1550nm 1310nm -40 ~ 75 ℃
MGB-TLA40 1000 WDM(LC) Single Mode 40km 1310nm 1550nm -40 ~ 75 ℃
MGB-TLB40 1000 WDM(LC) Single Mode 40km 1550nm 1310nm -40 ~ 75 ℃
MGB-TLA60 1000 WDM(LC) Single Mode 60km 1310nm 1550nm -40 ~ 75 ℃
MGB-TLB60 1000 WDM(LC) Single Mode 60km 1550nm 1310nm -40 ~ 75 ℃
36

Planet IGS-20040MT Specifications

General

Switch type	Managed
Switch layer	L2+
Traffic classification	Yes
Console port	RJ-45
Fiber optic connector	MiniGBIC
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4095
Networking standards	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Stackable	-
Certification	FCC, CE
Product color	Blue, White
Housing material	Aluminum
International Protection (IP) code	IP30
Fiber ethernet cabling technology	100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput	29.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Number of IP interfaces	8
Power consumption (max)	17 W
Power consumption (typical)	8 W
Heat dissipation	27 BTU/h
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	IPv4 / IPv6
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered	255
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107.3 mm
Width	76.8 mm
Height	152 mm
Weight	1043 g
