The Page includes the following fields:
Server Statistics
Object Description
The pa
ckets number that is relayed from client to server.
 Transmit to Server
The pa
ckets number whose errors are sending to clients.
 Transmit Error
 Receive from Server
The packets number that is received from server.
 Receive Missing Agent
Option
The packets number that is received without agent information options.
The pa
ckets number whose missing circuit ID is received.
 Receive Missing
Circuit ID
The pa
ckets number whose missing remote ID is received.
 Receive Missing
Remote ID
 Receive Bad Circuit ID
The packets number whose Circuit ID does not match known circuit ID.
Receive Bad Remote ID
The packets number whose Remote ID does not match known remote ID.
Client Statistics
Object Description
The pa
ckets number that is relayed from server to client.
 Transmit to Client
The pa
ckets number that is erroneously sent to servers.
 Transmit Error
The pa
ckets number that is received from server.
 Receive from Client
 Receive Agent Option
The packets number that is received with relay agent information option.
 Replace Agent Option
The packets number that is replaced with relay agent information option.
The pa
ckets number that keeps relay agent information option.
 Keep Agent Option
The pa
ckets number that drops relay agent information option.
 Drop Agent Option
Buttons
Auto-refresh : Check this box to refresh the Page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the Page immediately.
: Clears all statistics.

Planet IGS-20040MT Specifications

General

Switch type	Managed
Switch layer	L2+
Traffic classification	Yes
Console port	RJ-45
Fiber optic connector	MiniGBIC
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4095
Networking standards	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Stackable	-
Certification	FCC, CE
Product color	Blue, White
Housing material	Aluminum
International Protection (IP) code	IP30
Fiber ethernet cabling technology	100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput	29.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Number of IP interfaces	8
Power consumption (max)	17 W
Power consumption (typical)	8 W
Heat dissipation	27 BTU/h
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	IPv4 / IPv6
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered	255
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107.3 mm
Width	76.8 mm
Height	152 mm
Weight	1043 g
