User’s Manual of IGSW-24040T
STEP-2
According to your selection on the previous page, this wizard will create specific QCEs (QoS Control Entries) automatically.
First select the QCL ID for these QCEs, and then select the traffic class. Different parameter options are displayed depending on
the frame type that you selected.
Figure 4-9-4 Set up Typical Network Application Rules Page 2 Screenshot
The page includes the following fields:
Object Description
QCL ID
Select the QCL ID to which these QCEs apply.
Traffic Class
Select a traffic class of Low, Normal, Medium, or High to apply to the QCE.
Buttons
: Click to cancel the wizard.
: Click to go back to the previous wizard step.
: Click to continue the wizard.
173
