GENERAL INFORMATION
1.13
MODEL: 800 PRO X..........
MODEL NUMBER: S03NX8CS.
ENGINE MODEL: S2398--8070PA8C..
ELECTRICAL CAPACITIES
Flywheel I.D. 4010677 Fuel Tank 11.8 gallons (44.7 liters)...... ..........
CDI Marking 4010750 Oil Tank 3.25 quarts (3.1 liters)....... ............
Alternator Output 280 Watts Coolant 4 quarts (3.8 liters)... ............
Ignition Timing 29q BTDC@3500RPM Chaincase Oil 11/13 fl. oz.(325cc)..... .......
with TPS unplugged
0.2146s
5.4510mm
Spark Plug / Gap Champion RN57YCC / 0.025s (0.64mm)...
Voltage Regulator T1..
Electric Start N/A.......
Magneto Pulses 6....
SUSPENSION / CHASSIS CHAINCASE
Body Style PRO X Sprockets / Chain 25:40-76 P HYVO........ ...
Front Suspension PRO X Reverse Option.. ............
IFS Shocks Alum IFP/Threaded Brake Pads Type 81........ .........
IFS Spring Rate 90/180#/in. Chaincase Center Dist 7.92s (20.12cm..)....
Front Spring Preload 2.75s Thread Adjust Driveshaft Sprockets 2 Drivers Wide.
Front Vertical Travel 9.22s (23.4cm..) Brake Type Polaris HPB, Liquid Cooled.........
Rear Suspension PRO Xt...
Rear Axle Travel 13.86”(35.2cm..)...
Front Track Shock Ryde FX IFP w/ R/R (Preload 1.75”)..
Spring Rate 160#........
Rear Track Shock Ryde Fx IFP R/R..
Rear Torsion Springs .359s (sq.) / 77q
Track Type 15sx121sx1s (38.1x307.34x2.54cm..)........
Track Tension 3/8s -1/2s (1-1.3 cm..) slack with 10# (4.54kg) weight 16s (40.64cm..) ahead of rear......
idler shaft.
Overall Snowmobile Length 110s (279cm..).................
Overall Snowmobile Height 46s (117cm..).................
Maximum Snowmobile Width 48s (122cm..)...............
OPTIONAL REAR TORSION SPRINGS
SOFT MEDIUM(STD) FIRM
.347s(Sq.) Diameter x 77q .359s(Sq.) Diameter x 77q .405s(Sq.) Diameter x 77q
L.H. 7042101-067 L.H. 7042157--067 L.H.7042240--067
R.H. 7042102-067 R.H. 7042158--067 R.H.7042240--067
