REAR SUSPENSION/TRACK/TRACTION
7.26
Remove the compression head from the clicker as-
sembly housing by grasping the compression pin
with pliers and pulling straight out. (Picture 25)
ASSEMBLY:Install the compression head into the
clicker assembly housing, making sure the com-
pression pin is facing up. (Picture 26)
Fill compression housing with approximately 10cc
of shock fluid.
Set the compression clicker to the zero 0 position.
(Picture 27)
Pushing firmly down, reinstall clicker assembly into
housing. Special attention should be given to en-
sure the pin is positioned in the same location as it
was prior to removal. (Picture 28)
25
26
27
28
