Polaris 2014 RZR XP 1000 Service Manual

1.15
9924874 R02 - 2014 RZR XP / XP 4 1000 Service Manual
© Copyright 2013 Polaris Industries Inc.
Standard Bolt Torque Specification
BOLT SIZE
GRADE 2
FT. LBS. (NM)
GRADE 5
FT. LBS. (NM)
GRADE 8
FT. LBS. (NM)
1/4-20
5 (7) 8 (11) 12 (16)
1/4-28
6 (8) 10 (14) 14 (19)
5/16-18
11 (15) 17 (23) 25 (35)
5/16-24
12 (16) 19 (26) 29 (40)
3/8-16
20 (27) 30 (40) 45 (62)
3/8-24
23 (32) 35 (48) 50 (69)
7/16-14
30 (40) 50 (69) 70 (97)
7/16-20
35 (48) 55 (76) 80 (110)
1/2-13
50 (69) 75 (104) 110 (152)
1/2-20
55 (76) 90 (124) 120 (166)
Metric Bolt Torque Specification
BOLT
SIZE
GRADE
4.6 4.8 8.8 / 8.9 10.9 12.9
FT.— LBS. (NM) DRY THREADS
M3
.3 (.5) .5 (.7) 1 (1.3) 1.5 (2) 1.5 (2)
M4
.8 (1.1) 1 (1.5) 2 (3) 3 (4.5) 4 (5)
M5
1.5 (2.5) 2 (3) 4.5 (6) 6.5 (9) 7.5 (10)
M6
3 (4) 4 (5.5) 7.5 (10) 11 (15) 13 (18)
M8
7 (9.5) 10 (13) 18 (25) 26 (35) 33 (45)
M10
14 (19) 18 (25) 37 (50) 55 (75) 63 (85)
M12
26 (35) 33 (45) 63 (85) 97 (130) 11 (150)
M14
37 (50) 55 (75) 103 (140) 151 (205) 177 (240)
M16
59 (80) 85 (115) 159 (215) 232 (315) 273 (370)
M18
81 (110) 118 (160) 225 (305) 321 (435) 376 (510)
GENERAL INFORMATION
1
