Polaris 2014 RZR XP 1000 Service Manual

2
2.19
9924874 R02 - 2014 RZR XP / XP 4 1000 Service Manual
© Copyright 2013 Polaris Industries Inc.
Valve Clearance Inspection
NOTE: Valve clearance inspection should be
performed on a cold engine, at room temperature.
1. Remove the driver’s seat. Disconnect the negative
(-) battery cable.
2. Remove the engine access panel.
3. Remove eight screws retaining the outer clutch
cover.
4. Maneuver the outer clutch cover to allow access to
the drive clutch, in order to rotate the engine.
NOTE: Removal of left rear wheel or left rear
shock is NOT necessary to perform this
procedure.
5. Remove the spark plug wires to gain access to valve
cover as shown below.
6. Remove the four T40 bolts retaining the valve cover.
7. The engine will need to be rotated four times to
inspect all eight valve clearances (Item 13). Two
valves can be measured at each camshaft lobe
position.
NOTE: Remove spark plugs to aid engine
rotation.
MAINTENANCE
