Polaris 2014 RZR XP 1000 Service Manual

6.6
9924874 R02 - 2014 RZR XP / XP 4 1000 Service Manual
© Copyright 2013 Polaris Industries Inc.
PVT SYSTEM SERVICE
PVT Covers and Duct Components
1. CLUTCH DUCT INTAKE ASSEMBLY 11. BRACKET, COVER GUARD
2. CLAMP, WORM 12. AIR INLET DUCT
3. DECAL, CAUTION 13. SCREW
4. BOLT and WASHER 14. SCREW
5. COVER ASSEMBLY, OUTER 15. NUT, NYLOK
6. O-RING 16. BRACKET, BELT SCREEN
7. DRAIN PLUG, COVER 17. HOSE, AIR OUTLET
8. SEAL, COVER 18. INTAKE BOOT
9. SCREW 19. SEAL, COVER
10. COVER ASSEMBLY
CLUTCHING
