5.14
9924874 R02 - 2014 RZR XP / XP 4 1000 Service Manual
© Copyright 2013 Polaris Industries Inc.
Seat Assembly Rear
1. Seat Frame 7. Plate Seat Latch
2. Screw 4 ft-lb (5 Nm) 8. Screw 4 ft-lb (5 Nm)
3. Seat Base Assembly
9. Bolt
4. Seat Latch Lever 10. Seat Bottom
5. Spring Seat Latch
11. Seat Back
6. Plate Seat Latch
