Floor / Rocker Panels XP 4
1. Main Floor Upper
9. B-Pillar Cover LH
2. Rocker LH 10. Console Front
3. Rivet 11. Shifter Boot
4. U-Type Nuts
12. Seat Belt Boot Front
5. Block Off Flap
13. Console Rear
6. Main Floor Lower 14. Lower Rear Close-off Panel
7. Rocker RH
15. Upper Rear Close-off Panel
8. B-Pillar Cover RH 16. Floor Rear
