5.60
9924874 R02 - 2014 RZR XP / XP 4 1000 Service Manual
© Copyright 2013 Polaris Industries Inc.
37. Check shock for any leaks.
38. Reinstall the compression spring and the spring
retainer.
39. Thread the spring preload adjuster down against the
spring and set the preload to the specified
measurement (see Chapter 2).
40. Set the compression adjuster knob to the
recommended setting or the original setting upon
removal (see Chapter 2).
41. Remove the shock from the vise.
42. Reinstall spherical bearing O-rings and polyurethane
bushings.
NOTE: After installation, be sure to RIDE
SLOWLY initially to ensure the shock and the
vehicle’s suspension is performing correctly.
BODY / STEERING / SUSPENSION
